Atomos Ninja – Moniteur
Le prix initial était : 599,00 €.525,20 €Le prix actuel est : 525,20 €. HT 630,24 € TTC
En réapprovisionnement
Présentation Atomos Ninja
Atomos Ninja est un moniteur-enregistreur léger et compact HDR 10 bits de 5 pouces allant jusqu’à 4Kp60 en ProRes, ProRes RAW, Avid DNx, codec H.265, amplifiant les fonctions de monitoring et les capacités connectées. Il offre une nouvelle interface utilisateur ” AtomOS 11″. AtomOS 11 apporte une multitude de nouvelles fonctionnalités avancées de contrôle et d’enregistrement telles que RecordAssist, PlayBackAssist, SegmentPro, ELZone, Arri False color.
Ajoutez le module Atomos Connect à votre Ninja pour partager ce qui se trouve sur votre écran Atomos avec d’autres appareils connectés, iPads, Macs et Apple TV dans les mêmes locaux ou n’importe où dans le monde dajs Atomos RemoteView. Connect offre également 12G-SDI, le timecode et le contrôle sans fil AirGlu, le Wi-Fi 6 et le NDI.
Les partenariats étroits d’Atomos avec les principaux fabricants de caméras garantissent que Ninja fonctionne parfaitement avec une gamme croissante de DSLR et caméras Mirrorless.
Points forts Ninja
- Léger, robuste et fiable avec une nouvelle interface. Compatible avec la plupart des caméras HDMI
- Enregistre jusqu’au 4Kp60 en Apple ProRes, Avid DNxHD et maintenant H.265 (HEVC) inclus et jusqu’au 6Kp30 en Apple ProRes RAW
- Nouvel AtomOS 11 améliore la gestion de la mémoire, augmente la réactivité et libère de nouvelles fonctionnalités
- Atomos RemoteView* : Partage de l’écran Atomos avec les utilisateurs d’Atomos Connect, mais aussi Shogun Connect, iPads, Mac et Apple TV en local ou n’importe ou dans le monde
- Nouveaux outils pour organiser en amont l’enregistrement et le playback avec RecordAssistet PlayBackAssist.
- Compatible AtomX Cast et Atomos Connect offrant la connectivité SDI et flux de travail NDI
- Atomos Cloud Studio et les services du Cloud accessibles grâce à l’ajout de l’Atomos Connect
- Même taille que Ninja V, tous les accessoires sont compatibles avec la nouvelle gamme Ninja (Ninja & Ninja Ultra)
| Physical Specifications | |
| Dimensions (W x H x D mm) | 151 x 91.5 x 31mm |
| Weight | 360g / 12.7oz |
| Rack height | |
| Mount points | 1 x anti-rotation 1/4-inch / 3/8-inch top and bottom |
| VESA mount | |
| Rack mount | |
| Dual display | |
| Dual recorder | |
| Environmental | |
| Ambient operating temperature | Up to 40 degrees Celsius |
| Storage temperature | |
| Relative humidity | |
| Construction & Control | |
| Body | Aluminium with ABS plastic |
| Cooling | Actively controlled fan and heat sink |
| Tally light | Rear and front |
| Control buttons | |
| Multi-function button | Power / lock screen |
| AtomXpansion slot | Yes |
| Master control unit (MCU) | |
| Power | |
| Input voltage | 6.2V to 16.8V |
| Operating power | 5.8-7.2v (Battery) or min 30W via USB C PD cable |
| Compatible batteries | NPF L series |
| Built in battery | No |
| Battery voltage | |
| Battery run time Record | 5200mAh – up to 2hrs (monitor & record 4K 60p) |
| 7800mAh – up to 3hrs (monitor & record 4K 60p) | |
| Battery run time Monitor Only | |
| Continuous power | |
| DC in connector | Via DC jack on battery eliminator |
| DTAP | Via battery eliminator and optional DTap to DC cable |
| DC out | |
| Display | |
| Touchscreen | SuperAtom IPS panel (capacitive touch) |
| Size | 5.2-inch |
| Resolution | 1920 x 1080 |
| Viewing angle | |
| Screen coating | |
| PPI | 427 |
| Bit depth | 10-bit (8+2 FRC) |
| Backlight Type | Edge lit |
| Brightness (cdm2 / Nits) | 1000 |
| Black Level (cdm2 / Nits) | |
| Aspect ratio | 16:09 |
| De-interlace mode | |
| Color Gamut | Rec.709 |
| Calibration support | Atomos Calibrator with Calibrite ColorChecker Display Pro & ColorChecker Display Plus |
| Color Pipeline | |
| Gamma | Sony SLog / SLog2 / SLog3, Canon CLog / CLog2 / Clog3, |
| Arri Log CEI160 / LogCEI200 / LogCEI250 / LogCEI320 | |
| / LogCEI400 / LogCEI500 / LogCEI640 / LogCEI800 / | |
| LogCEI1000 / LogCEI1280 / LogCEI1600, Panasonic Vlog, | |
| JVC JLog1, Red LogFilm / Log3G10 / Log3G12, FujiFilm | |
| Flog, PQ (HDR10), HLG, Nikon N-Log | |
| Gamut | Bt2020, DCI P3, PDCI p3 65 Sony SGamut / SGamut3 / SGamut3.cine / |
| Canon Cinema / DCI P3 / DCI P3+ / BT2020 | |
| Panasonic V Gamut | |
| Arri Alexa Wide Gamut | |
| Rec709 | |
| JVC LS300 | |
| Red DragonColor / DragonColor2 / RedColor2 / | |
| RedColor3 / RedColor4 / RedWideGamut | |
| 3D LU+A76T Display | .Cube Format |
| 3D LUT Down Stream | Loop out |
| 3DLUT 50/50 | Yes |
| Monitoring Modes | Native / HLG / PQ / 3D LUT |
| HDR output Conversion | Log / HDR to HLG / PQ / Dolby Vision |
| Video Input | |
| HDMI | 1 x HDMI (2.0) 4Kp60 |
| HDMI RAW | Apples ProRes RAW up to 6K with compatible cameras |
| SDI | Optional Via Atomos Connect module |
| SDI RAW | Optional Via Atomos Connect module |
| RJ45 / Network | |
| Wi-Fi | |
| USB | |
| Bit Depth | 8/10-bit video / RAW up to 16-bit |
| Video Chroma Subsampling | 4:2:2 |
| HDCP copy protection | Not supported |
| Metadata | |
| HDMI | RAW – white balance, exposure index, shutter speed/angle, Iris F stop, ISO, gamma, gamut |
| SDI | |
| External input | |
| Closed captioning | |
| Video Output | |
| HDMI | 1 x HDMI (2.0) 4Kp60 |
| SDI loop out | |
| SDI Play out | |
| RJ45 / GigE | Optional Via Atomos Connect module |
| Wi-Fi 6 | Optional Via Atomos Connect module |
| Multiview | |
| OS overlays | |
| Video Chroma Subsampling | 4:2:2 |
| Bit Depth | 10-bit video |
| Pattern Generator | |
| Web Streaming | |
| USB UVC | Optional Via Atomos Nexus 4K or AtomX Cast |
| RJ45 / GigE | Optional Via Atomos Connect module |
| RTMP / S | Optional Via Atomos Connect module |
| RTSP | |
| SRT | |
| Video Signal Conversion | |
| HDMI to SDI | Optional Via Atomos Connect module |
| SDI to HDMI | Optional Via Atomos Connect module |
| Audio In/Out | |
| Audio Quality | 24/48kHz |
| Audio Codec | PCM |
| HDMI | 8ch 24-bit, input dependent |
| SDI | 12ch 24-bit, input dependent |
| Analogue Audio in | 3.5mm 2ch. |
| Analogue Audio Out | |
| Speakers | |
| Headphone out | 3.5mm 2ch. |
| Audio input delay | User definable from menu |
| Timecode / Sync / Control | |
| Embedded | HDMI and SDI |
| Time of day | Yes, Time and Date |
| Reference input | |
| LTC | Optional Via Atomos Connect module |
| Genlock | Optional Via Atomos Connect module |
| Wireless AirGlu RF Server and Client | Optional Via Atomos Connect module |
| Wireless AirGlu BT Server | Optional Via Atomos Connect module |
| Resolution & Frame Rates (Record, Monitor & Playback) | |
| Supported base resolution & FPS | |
| 8K | |
| 6K | RAW Only up to 30p via HDMI |
| 5K | |
| 4K DCI | 23.98/24/25/29.9/30/50/59.94/60p |
| 4K UHD | 23.98/24/25/29.9/30/50/59.94/60p |
| 2K DCI 2046 x 1080 | Optional via AtomX SDI module |
| Anamorphic | 3.5k: RAW up to 60p (from supported cameras only) |
| FHD 1920 x 1080 Progressive | 23.98/24/25/29.9/30/50/59.94/60/100/120p |
| FHD 1920 x 1080 PsF | converted to P and looped out PsF |
| FHD 1920 x 1080 Interlaced | 23.98/24/25/29.9/30/50/59.94/60i |
| 1280 x 720p | 50/59.94/60p |
| SD PAL / NTSC | |
| Recording CODEC | |
| CDNG | |
| Apple ProRes Raw | ProRes RAW, HQ |
| Apple ProRes | LT, 422, 422HQ |
| Avid DNxHD | DNxHD 220x,220,145,36 |
| Avid DNxHR | LB, SQ, HQ, HQX. |
| H.265 | LQ,MQ,HQ,XQ in 8/10Bit, 4 2 2 and 4 2 0 |
| H.264 | |
| Playback | |
| Playlist | Yes, Create customer play lists from full or sub clips |
| Loop | Yes, with user customisable in / out markers |
| CDNG | |
| Apple ProRes Raw | Yes, recorded clips |
| Apple ProRes | Yes, with Linear PCM audio |
| Avid DNx | Yes, with Linear PCM audio |
| H.265 | Yes |
| H.264 | |
| Recording functions | |
| Pre-roll record | Yes (HD 8s, 4K 2s) – Not available in RAW |
| ISO Record | |
| Switched Program Record | |
| Timelapse | Yes |
| RAW to Video Record | |
| Simultaneous proxy record | Yes |
| 4K to HD | |
| Multi Input / Switching | |
| SDI A/B toggle | |
| Dual Input display | |
| Multiple SDI input | |
| Multiple HDMI input | Optional via AtomX Cast |
| Multiview Display | Optional via AtomX Cast |
| Multiview Ouput | Optional via AtomX Cast |
| Picture in Picture (PIP) | Optional via AtomX Cast |
| Picture and Picture (PAP) | |
| Graphic overlays | Optional via AtomX Cast |
| Media pool storage | |
| Input transitions | Optional via AtomX Cast |
| Input Resolution Processing | |
| Input Image processing | |
| Keyer | |
| Supported media | |
| Master Caddy I | Not compatible |
| Master Caddy II | For 2.5-inch hard drives in MasterCaddy II |
| Master Caddy III | For 2.5-inch hard drives in MasterCaddy III (needed for Atomos Connect) |
| SSDmini | Native size and fit |
| CFAST II | With supported cards via optional SSDmini CFAST II Adaptor |
| SD | |
| USB | |
| Network | |
| File Naming | Unit Name – Scene/Shot/Take |
| File System | ExFAT |
| On screen tools | |
| MultiScope Analysis View | |
| Waveform | Yes, 3 size / Position |
| Histogram | |
| RGB parade | Yes, 3 size / Position |
| Vector scope | Yes, 2 size / Position |
| 1 x Zoom | Yes. 1:1 Pixel mapping for 4K |
| 2 x Zoom | Yes |
| 4 x Zoom | |
| Focus peaking | Colour selected / threshold setting / colour |
| / Mono / edges only | |
| Atomos False color | Yes, with Scale |
| ARRI False color | Yes |
| EL Zone | Yes |
| Zebra | Yes, Adjustable |
| Isolate color channel | Blue Only |
| Cine Frame Guides | 2.4:1, 2.35:1, 1.9:1, 1.85:1, 4:3 |
| Social Frame guides | 9:16, 1:1, 191:1, 4:5 |
| Onion Skin | Yes |
| Safe areas | Action and Graphic |
| Grid markers | 9 grid |
| Anamorphic desqueeze | 1.25x, 1.33x, 1.5x, 1.6x, 1.65x, 1.79x, 1.8x, 2x |
| Display Flip | Vertical Only |
| Onboard Signal Processing | |
| Pulldown removal | 24/25/30pSF > 24/25/30p (2:2 pulldown) |
| 60i > 24p (3:2 pulldown) | |
| 4K UHD downscale for HD | Loop out – 4K UHD to FHD |
| DCI Crop | Loop out – 17:9 to 16:9 Crop |
| Remote Control | |
| HDMI | Auto HDMI Trigger, Supported Protocols – Canon, Sony, |
| Atomos Open Standard | |
| SDI | SDI trigger camera selectable with Atomos Connect |
| Serial 2.5mm Jack | LANC control and calibration via |
| optional USB to serial cable | |
| AirGlu BT | Optional Via Atomos Connect module |
| AirGlu RF | Optional Via Atomos Connect module |
| USB | |
| RJ45 | |
| RS422 | |
| External Device Control | |
| Serial 2.5mm Jack | Camera control for supported cameras via Optional USB to Serial Cable |
| Bluetooth LE | Optional Via Atomos Connect module |
| Wireless RF | Optional Via Atomos Connect module |
| USB | |
| RJ45 | |
| Supported Applications | |
| XML | Cut tag EDL in FCPX XML |
| Apple ProRes Raw | Apple FCPX, Adobe Premiere, After Effects, Avid Media Composer, GrassValley Edius, Assimilate Scratch, Baselight Film Light. |
| Video Codecs | All Applications with support for Apple ProRes and Avid DNx in .MOV wrapper |
| What’s in the box | |
| Accessories included | Ninja, 1 x battery eliminator, 1 x USB C PD to 2.1mm DC power lead and QuickStart Guide |
| Software included | |
| Optional extras | Accessory Kit 5-inch Vers II, Sunhood, DC to DTap, Power kit, HDMI cables, USB to serial cable, |
